Gateway / Bridge Converter

from PROFIBUS in J1939



Order Code Price info Details Description User manual Operating Temperature
HD67553 View J1939 / PROFIBUS Slave - Converter
( Housing type: A, Terminal Blocks Connectors )
-40° to +85°
HD67436 View J1939 / PROFIBUS Master - Converter
( Metal enclosure, Triple Galvanic Isolation: 4KV, PCB Treatment )
-40° to +105°
HD67437 View J1939 / PROFIBUS Slave - Converter
( Metal enclosure, Triple Galvanic Isolation: 4KV, PCB Treatment )
-40° to +105°


Specifications:
Ports: 1xJ1939; 1xPROFIBUS; 1xRS232
Data Rates J1939Up to 1 Mbps
Data Rates PROFIBUSUp to 12 Mbps
Power supply24VDC 200mA; 12/18VAC 50/60Hz 200mA
Operating temperatur-30° to +70° (-22°F to +158°F)
Dimensions120x23x107 (DxWxH)
Weight200g approx
Mechanical fixingDIN Rail montage
SoftwareSW67553
ORDER CODE:HD67553


Accessories:
Order Code   Description Details
AC34001   Power Supply 220/12V AC 50/60Hz View
AC34002   Power Supply 110/12V 50/60Hz View
AC34107   Null Modem Cable, Fem/Fem, DSub 9 Pin, 1.8 m View
AC34114   Null Modem Cable, Fem/Fem, DSub 9 Pin, 5 m View

Benefits:
Software for easy configurator
Designed for serius use
Very easy to configure
Low cost
Rail din mountable
Wide supply input range
Galvanic isolation
Industrial temperature range:
  -30° / 70° (-22°F / 158°F)
