Gateways / Bridges

CANopen to CANopen

Order Code Price info Details Description User manual Operating Temperature
HD67121 View CANopen / CANopen - Converter
( Housing type: A, Terminal Blocks Connectors )
-40° to +85°





Specifications:
Ports: 2 x CAN 2.0; RS232C
Data Rates CAN From 10K up to 1M bps
Max Distance5.000 m. for 10K bps;25 m for 1M bps
Power supply24 VDC 200mA; 12/18V AC; 50/60 Hz;200mA
DIP SwitchDifferent Baud Rate Setting
LED1 x Power indicator;2 x Signal indicator
Operating temperatur-30° to +70° (-22°F to +158°F)
Dimensions120x23x107 (DxWxH)
Weight200g approx
Mechanical fixingDIN Rail montage
SoftwareSW67121
ORDER CODE:HD67121

Benefits:
Software for easy configurator
Designed for serius use
Very easy to configure
Low cost
Rail din mountable
Wide supply input range
Galvanic isolation
Industrial temperature range:
  -30° / 70° (-22°F / 158°F)


Accessories:
Order Code   Description Details
AC34001   Power Supply 220/12V AC 50/60Hz View
AC34002   Power Supply 110/12V 50/60Hz View
AC34107   Null Modem Cable, Fem/Fem, DSub 9 Pin, 1.8 m View
AC34114   Null Modem Cable, Fem/Fem, DSub 9 Pin, 5 m View
