HD67672-485-A1
BACNet / RS485 Slave - Converter
( Ethernet Switch Inside for enter/exit connection,
Housing type: A, Terminal Blocks Connectors )
Prices and Shipping info
|
|
Specifications: |
Ports: | 1xRS485; 2xBACnet |
Data Rates Serials | Up to 115200bps |
Data Rates BACnet | 10/100 Base-T Autosensing |
Serials connector | 3way 5mm removable screw terminal |
BACnet connector | RJ45 |
Power supply | 8..24V AC; 12..35V DC |
Power supply connector | 2way 5mm terminal block |
Operating temperature | -40° to +85° (-40°F to +185°F) |
Dimensions | 120x23x107 (DxWxH) |
Weight | 200g approx |
Mechanical fixing | 35mm DIN Rail montage |
Software | SW67672 |
ORDER CODE: | HD67672-485-A1 |
