J1939 / CAN - Converter

This serie of products allows to integrate a J1939 network with a CAN net.


The HD67047 is a J1939 / CAN Converter and it allows you to connect a J1939 net (for example a common engines based on SAE J1939, joysticks ) with a CAN network in order to exchange the informations between the networks.


The converters are available also in another version, ideal for STRONG applications.

The corresponding models are:

  • HD67439 - J1939 / CAN, STRONG Converter

    • These converters are contained in a metal housing, so it is STRONG and RESISTANT to the vibrations and shocks. The electrical parts are with triple isolation of 4000 V between J1939/CAN - J1939/Power Supply - CAN/Power Supply.
    Particularly suitable for the installation on cars, trains, boats, industrial sector and in fragile environments.
    Two versions, one with Varnished PCB and one with Resined PCB.
    Varnished treatment gives dust and humidity protection, Resined treatment gives high water, dust and vibrations protection.
    Excellent range of temperature resistance from -40 C to +105 C, features required by AUTOMOTIVE applications.




    Order Code Price info Details Description User manual Operating Temperature
    HD67047-A1 View J1939 / CAN - Converter
    ( Housing type: A, Terminal Blocks connectors )     		-40° to +85°
    HD67439 View J1939 / CAN - Converter
    ( Metal enclosure, Triple Galvanic Isolation: 4KV, PCB Treatment )     		-40° to +105°




    Accessories:
    Order Code   Description Details
    AC34011   Isolated Converter 100..240V AC to 12V DC stabilized - AC/DC View
    AC34012   Isolated Converter 100..240V AC to 24V DC stabilized - AC/DC View

    Benefits:
    Software for easy configurator
    Designed for serius use
    Very easy to configure
    Low cost
    Rail din mountable
    Wide supply input range
    Galvanic isolation
    Industrial temperature range:
      -30° / 70° (-22°F / 158°F)
    All Products

































    Sample within:

    Europe: One days
    U.S.A.: Two days
    Other Countries: Three days
